Ateva Technologies

SOFTING

echocollect -e

La passerelle echocollect -e

La passerelle Echocollect est une passerelle dédiée à l’intégration des données “Process Data” vers des systèmes de hauts niveaux ou de solutions IoT.

La passerelle echocollect -e est une passerelle multi protocoles fournissant des solutions de managment “Process Data”. Elle offre des connexions “temps réel” entre PLC et bases de données,  OPC UA et OPC Classic connectivité. Ses fonctionnalités inclues à la fois le log de données locales et une intégration directe de données d’applications Cloud IoT via MQTT





Vous ne connaissez pas l’ echocollect ???

Présentation Echocollect  ( PDF )

Général

Integration of Existing Systems in New Quality Assurance Systems

  • Independent real-time collection of manufacturing, process or quality data directly from programmable logic controllers (PLC) and delivery to higher-level management systems, such as ERP or MES system
  • Recipe manager functionality for writing data blocks to PLCs
  • Direct connectivity via SQL database protocols, platform independent OPC UA technology or MQTT Publisher functionality
  • Support of more than 50 PLC types addressable via Ethernet

Excellent Data and Network Security

  • Buffering of arriving data and addition of time stamps in case of broken connections, automatic forwarding once connection has been reestablished
  • Option for parallel data logging on SD card for traceability reasons
  • Physical network separation between production systems and commercial IT networks
  • State-of-the-art OPC UA security: Optional encryption of transmitted data and authentication via certificates

Lowered IT Maintenance Costs and Investment Protection

  • echocollect as standard component, addition of extra functionality without modifying existing systems
  • No need for additional PC requiring software updates and administration
  • Working for years once configured – untouched, without updates and with zero maintenance costs
  • Plug-and-go replacement, if necessary, using configuration stored on SD card
  • Very easy configuration by straightforward project import without requiring PLC modifications and programming skills

Easy Live Data Visualization

  • Native web technology for easy and cost-efficient visualization of process, manufacturing and quality data using standard web browser without any plug-ins
  • No need for OPC Server or complex SCADA system
  • Scalable, resolution-independent vector graphics for consistent display of data on wide variety of network enabled devices like desktop PCs, laptops, smart phones, tablet PCs or industrial control panels

Details Techniques

Ethernet Addressable Controllers Siemens SIMATIC S7 and S5, controllers with Modbus TCP (Wago, Beckhoff, Phoenix Contact, Schneider Electric, etc.), Mitsubishi (Melsec-Q), etc.
Ethernet Protocols TCP/IP, RFC1006 (ISO on TCP), ISO (H1), S5, S7, TCP/IP with PLC header, Modbus TCP, Melsec-Q, raw data
Ethernet Interfaces 2 x independent interfaces TP (RJ45), 10/100 MBit/s
Embedded OPC UA Server Symbolic Mapping; Browsing, Read, Write, Subscribe; Self-Discovery Service; possible reconfiguration without device restart; possible multiple Client connections, optional read-only PLC connection; OPC UA Security with password or certificates
Embedded MQTT Publisher Establishment of MQTT Broker connection, optional user authentication and data encryption, easy topic generation from existing symbols, maximum of 1,000 topics, adjustable publishing interval
Supported Databases MySQL, Oracle, DB2, MS-SQL
Other Protocols Telnet, SMTP (email notification), OPCpipe (OPC Tunnel)
Supported Engineering Tools for Symbol Import SIMATIC STEP 7, TIA Portal
Limitation Maximum of 5 PLC connections, 10,000 items in total
Data mapping PLC – database must be structured in 400 tables and 200 items per table
Visualization atvise webMI visualization, functional level ‘Advanced’ (fully event-driven data exchange) Limited to up to 50 visualized items per echocollect (optional upgrade possible), maximum of 5 simultaneously accessing browsers
Configuration Software Softing NetCon for device configuration, atvise builder for SCADA project editing, dataFEED Exporter for symbol import
Power Supply 24 VDC, ca. 0,3 A
Ambient Conditions Operating temperature: 0 °C … 55 °C, storage temperature: -20 °C … 70 °C
Dimensions (HxWxL) 131mm x 47mm x 111mm
Weight ca. 0,4 kg
Mounting 35 mm DIN Rail
Protection Class IP20
Certifications CE

Références

GAL-YY-143101 echocollect e (connectors: 2 x Ethernet, 1 x TTY)
LRA-YY-143001 Upgrade echocollect: License for database access to Oracle, DB2 and MSSQL (default: MySQL only)
LRA-YY-143002 Upgrade echocollect: License enabling data logging on SD Card (default: no data logging)
LRA-YY-143004 Upgrade echocollect: License supporting unlimited number of visualization items (default: maximum of 50 visualization items)
LRA-YY-143005 Upgrade echocollect: License embedded OPC UA Server (default: no embedded OPC UA Server)
LRA-YY-143007 Upgrade echocollect: License MQTT Publisher functionality (default: no MQTT support)
LRA-YY-143115 Upgrade echocollect: License enabling maximum of 15 PLC connections (default: maximum of 5 PLC connections)

Additional Products and Services

700-5596-04 AC Adapter, 24 VDC, Euro, UK, or USA
LRL-DY-131701 OPCpipe client
MEA-YY-144002 CD atvise elements, 4,000 high-quality bitmaps and vector graphics in SVG format
GPL-CS-191000 echolink sS7-compact
110-1000-01 Industrial Ethernet – Troubleshooting in Automation, 3 days

Scope of Delivery

Hardware Multi-protocol gateway echocollect e, SD card, connector for power supply*
Software Net configuration software on CD-ROM, also downloadable from Softing website
Documentation Quick Start leaflet, context-based online help, CD-ROM with product handbook and configuration tutorials, also downloadable from Softing website

accessoires

Connector Power Pack 24 V DC
Country-specific connector power packs are available. Note: A connector power pack is not included in the delivery of the echocollect. If necessary please order it separately.

Technical Details

100 – 240 V AC, 47 – 63 Hz, sec. 24 V, 1,25A

Order Number

Version EURO, UK, USA
700-5596-04

Wiki

Which cloud platforms are supported?

We support with all Softing gateways (echocollect, uaGate, edgeGate) the Microsoft Azure Cloud, Amazon AWS Cloud, IBM Bluemix Cloud and other cloud providers, which are using MQTT for telemetry data.

What is the size of the Store & Forward queue on the echocollect?

The S&F queue for MQTT is unlimited (except the size of the sd-card). The echo buffers in the ram, and after it collects a bunch of messages, they were copied to the sd-card. To use the S&F feature, QoS 1 or QoS 2 must be used.

Les personnes intéressées par ce produit, peuvent être intéressées par :

CAN-AC2-PCI

CAN-AC2-PCI

Carte Universelle PCI avec micro contrôleur

Interface CAN simple ou double canaux, au format PCI pour réseaux CAN et CANopen

Généralités

Interface fléxible pour PC embarqués et industriels

  • Data exchange between PC applications and connected CAN bus
  • Available in single and dual channel versions
  • Universal solution matching almost any CAN application
  • Use, for instance, in machine controllers, PC-based applications, test rigs or real-time simulations
  • Integration in Mathworks xPC Target

Rapid Integration with right Software Interface

  • Flexible API including FIFO storage buffering all sent and received messages, separately for each channel
  • No data loss when computer working on other tasks
  • Filtering and buffering of messages of interest
  • Automatic transmission of data to bus in exact, individually configurable cycles
  • Free CANopen Client API available for use in CANopen networks

Application in a Wide Variety of Target Systems

  • Use in Windows operating systems
  • Linux driver
  • Sample projects for C, C# or VB.NET with commented source code

Détails Technique

Single Channel Dual Channel
CAN Protocol and Available APIs
CAN V2.0 (11/29 Bit IDs)
CAN API
CANopen Client AP
CAN Bus Connection
Connector 9-pin D-sub male
No. of Channels 1 2
Galvanically Isolated
Physical Layer ISO 11898-2 (CAN High Speed)
PC Interface PCI Rev. 2.1, 4 KB DPRAM
Interrupts Plug-and-play
Operating Temperature 0 °C … +70 °C
Storage Temperature -20 °C … +70 °C
Relative Humidity < 90%, non-condensing
Dimensions 160 mm x 100 mm
Power supply
Supply voltage 5 VDC (±5 %)
Current consumption Typically 380 mA Typically 410 mA
Drivers available for Windows XP, Windows 7, Windows 8, Windows 10, Linux
Conformity

Références

CAN-AC1-PCI Single Channel
CAN-AC2-PCI Dual Channel

Scope of Delivery

Hardware PC interface board
Software Drivers, APIs, sample programs on CD-ROM
Documentation On CD-ROM

Formation

CAN and CANopen have a permanent place in the industrial environment. The reliability and robustness are important aspects for optimal operation. Efficient failure analysis and fast troubleshooting contribute to the high availability in networks.

During our training you learn everything from A to Z on CAN and CANopen for daily practice. We teach you the necessary specific knowledge to plan, operate and maintain CAN networks.

Certificats

ISO 9001 Certificate (PDF)

RoHS Certificate (PDF)

WEEE Certificate (PDF)

REACH Certificate (PDF)

The CAN-AC2-PCI has no ITAR  classification

The CAN-AC2-PCI has no ECCN  classification

PB-LSZ-CHB3

Pince pour mesure de courants de fuite

pb-lsz-chb3_640x640

La pince PB-LSZ-CHB3 permet la mesure de courants de fuite; eg : fuite, Measures leakage currents, e.g. leakage and fault currents, and current pick-up of instruments without breaking the circuit. Measurements according to DIN VDE 0701/0702 and the German BetrSichV (BGV A3, VBG 4).

  • D’une fiabilité redoutable, cette pince détecte des courants de fuite très faitble, résultant de problèmes de champs ElectroMagnétique ( EMC )

    Fonctionnalités PB-LSZ-CHB3:

  • Mesure de courants de fuite
  • Mesure de courants différentiels
  • Mesure de résistance et tension
  • Fréquence de mesure pour Courant alternatif / Tension  40 Hz…1 kHz
  • Test de continuité accoustique
  • MIN/MAX et mesure relative
  • Sélection manuel de la plage de mesure
  • data hold intégré
  • Affichage bar graph additionnel
  • Ouverture de la pince : ouvrant jusqu’à : 30 mm
  • Extension automatique

Pince numérique pour la mesure des coutants de fuite :  2 batteries 1.5 V IEC LR6, housse de protection, cables de mesure (1 x rouge, 1 x noir) et manuel utilisateur.

Ref : ATV-DDA-ZZ-004010 ( anciennement :PB-LSZ-CHB3 )

CANPro USB

canprousb_d_en_160801_201

CANPro USB : Interface USB “High Speed” vers interface CAN, pour une utilisation mobile

CANPro USB équipe un PC, un ordinateur portable avec des preformances optimales, des réponses rapides de l’interface CAN. Le CANPro USB correspond à de larges utilisations de CAN et CANOpen, comme le contrôle, la mesure, la confirguration et l’analyse de tache. Il est disponible dans une version “Heavt Duty”

Général

Un débit de données élevé grâce à un temps de réponse court

  • Standard USB 2.0 “High Speed”
  • Une des interfaces CAN les plus rapides du marché
  • Processeur et rapidité optimisé par firmware. conçu pour 100% de charge de bus à 1 Mbit/s
  • Débit de données élevé, grâce à un temps de réponse de 100 μs à 500 μs
  • Convient à une large gamme d’applications, incluant les applications ou le timing est une variable critique
  • Très simple d’utilisation
  • Status USB et CAN affichés par LED
  • Installation facile par connexion du cable USB vers le PC et connecteur ‘D-Sub’ vers réseaux CAN
  • Aucune alimentation électrique nécessaire.

Convient pour des applications “statiques” et “mobiles”

  • Petit et robuste, désign métalique qui convient à un usage de tout les jours
  • S’adresse aussi bien a des applications mobiles que standards
  • Une version “Heavy duty” disponible offrant un cable USB fixé et sécurisé et un kit de montage sur PC. Idéal pour applications industrielles en environnement dur

Fonctionalité facile supportant une large variété d’utilisations

  • Intégration facile dans vos applications CAN
  • APIs basé sur  C et .NET
  • Support d’une FIFO et d’un mode “objet buffer”
  • API Client CANopen gratuit, pour intégration d’applications comme le contrôle et la mesure, la configuration et l’analyse

Détails Téchniques

CAN Protocol and Available APIs CAN V2.0 (11/29 Bit-IDs)
CAN API
CANopen Client API
Bus Connection
Connector 9-pin D-sub male
Galvanically Isolated Yes
Physical Layer ISO 11898-2 (CAN High Speed)
PC Interface USB 2.0 High Speed, 480 Mbit/s
Indicators
USB LED USB status
CAN LED CAN status
Operation Temperature 0 °C … +55 °C (standard version) / -20 °C … +70 °C (heavy duty version)
Storage Temperature -20 °C … +70 °C (standard version) / -20 °C … +70 °C (heavy duty version)
Relative Humidity < 90 %, non-condensing
Dimensions 74 mm x 55 mm x 26 mm
Power supply
Supply Voltage 5 VDC (±5 %) via USB connector
Current Consumption Typically 200 mA
Drivers Available for Windows XP, Windows 7, Windows 8, Windows 10, Linux
Conformity

Références

DUL-OO-012410 CANpro USB (Version standard)
DUL-OO-012411 CANpro USB (Version ” renforcée “)

Scope of Delivery

Hardware (Version Standard ) CANpro USB ( version standard ), Cable USB
Hardware (Heavy Duty Version) CANpro USB (heavy duty version), lockable USB cable with cable connector and mounting kit
Software Drivers, APIs, sample programs on CD-ROM
Documentation Manual on CD-ROM

Formation

Contactez nous pour des formations CAN – Formation disponible en langue Anglaise uniquement

BC-502-PB

Le BC-502-PB – pour PROFIBUS DP

BC-502-PB : moniteur de reseau PROFIBUS DP, pour une analyse de vos réseaus PROFIBUS DP : 24H/24

Moniteur Réseau PROFIBUS DP

PROFIBUS DP Moniteur (BC-502-PB)

Disponibilité maximale grâce au moniteur BC-502-PB, de bus PROFIBUS DP

Le moniteur PROFIBUS DP ( BC-502-PB) est un “inspecteur” de reseaux. Il analyse de façon continue, les données qui transite sur le réseau PROFIBUS DP..Dans le cas ou l’outils detecte un echange critique qui pourrait amener à une panne du réseau, il génère automatiquement une notification de disfonctionnement et une action préventive peut être effectué.

  • Prévient de pertes de production dans le cas de problèmes de bus
  • Permets la planification des maintenance réseaux
  • Facile a utiliser, via une interface Web intégré
  • Etat de chaque esclave sur le bus PROFIBUS DP

Apperçu

le BC-502-PB permet la détections rapide des problèmes de bus

Le moniteur PROFIBUS se fixe dans un rack de contrôle, ( Rail DIN ). On dispose d’un moniteur par ligne de bus PROFIBUS, indépendement du nombre physique de segments a analyser. Le BC-502-PB détecte les déteriorations de la communication du bus et les rapporte. Cela permet d’établir une stratégie  de maintenance, qui réduit les interventions des équipes, seulement en cas de besoin. Les ressources maintenance sont alors optimisées.

Le BC-502-PB permet une lecture facile et simple.

Aucun changement d’adresse ni même de programmation de la PLC n’est nécessaire., lors de l’installation du moniteur PROFIBUS. La configuration et la visualisation sont fait via le réseau, grâce à une interface web intégrée.  le debug, l’analyse des problèmes demande une connaissance minimum des réseaux PROFIBUS.



Le BC-502-PB  avertit des pannes prochaines….

En se connectant sur un segment PROFIBUS, le moniteur PROFIBUS détecte automatiquement, la vitesse de transmission ( Baud Rate ) et démarre instantanément l’analyse du réseau PROFIBUS DP. Il détermine les temps de cycles et compte les événements critiques. Les événements critics sont : les erreurs de trames, redémarrage, les messages de diagnostics.. De cette manière, les détériorations lentes du réseau, dû à l’age de l’installation, sont rapidement détectées. Quand le nombre d’erreurs dépasse une limite par unité de temps, le moniteur PROFIBUS envoie une alarme à la PLC via un contact, ou ( optionel) vers le réseau Ethernet. Les 100 dernières alarmes sont stockées sous forme de liste. Dans le cas d’une apparition d’alarmes, le BC-502-PB permet de retrouver l’historique de la période en question. Le fichier trace peut etre analysé ultérieurement grâce à l’outil PROFIBUS Diagnostics Suite.



Détails techniques

Power Supply DC 24 V +/–20%, typ. 0.3 A, max. 1 A
PROFIBUS PROFIBUS Protocols: DP, DPV1, FMS, MPI; Connection: 9-Pin D-Sub, Baud Rates: 9.6 Kbit/s .. 12 Mbit/s
Ethernet 100BASE-TX, 10BASE-T, Connection: RJ45, IP Address: Manually or via DCHP
RS232 Reserved
USB Only available with BC-502-PB/CL Option
Control Signals Potential-free Contact, 3 Inputs DC 24 V, Active High
Dimensions HxWxD: 131 x 47 x 111 mm
Weight Approx. 0.4 kg
Mounting 35 mm DIN Rail
Protection Class IP20
Operating Temperature 5 °C to 55 °C
Storage Temperature –20 °C to 70 °C
Conformity CE, FCC, VCCI
Display & Parameterization Via Integrated Web Interface
Snapshot Analysis Via PROFIBUS Diagnostics Suite PC Software, see separate Data Sheet

Numéro de référence

BC-502-PB PROFIBUS Monitorr for Continuous Bus Monitoring and Condition-based Maintenance of DP/DPV1/FMS/MPI, DIN Rail Mounted, External 24 VDC Power Supply Required, Signaling
Contact, Control Inputs, Ethernet 10/100BASE-T(X),RJ45, Integrated Web Server, User Manual, PB-DIAG-SUITE Analysis Software (See seperate Tab.)
BC-502-PB-START PROFIBUS Monitor Start Package Consisting of BC-502-PB, BC-131-PB, AC Adapter/Cable, Patch/Crossover Cable and Carrying Case

Additional Products and Services

BC-131-PB Optional Active Connection Cable for Hassle-free Integration into Existing or Running Installations Without Recabling or the Disturbances Caused by a Spur Cable, 3m Length, Bus-powered Internal Repeater
BC-502-PB/CL “Comfort Line” Option, Allows Full-Featured Protocol Analysis via USB, Supplied as Activation Code
BC-502-PB/SNMP “Premium Line” Option, Provides SNMP Network Interface for Measurement Data, Supplied as Activation Code
BC-502-PB/CLP “Comfort Line Plus” Option, Allows Full-featured Protocol Analysis via USB and Provides SNMP Network Interface for
Measurement Data, Supplied as Activation Code
TRA-PB-TECH PROFIBUS Technology Training, 2-Day
TRA-PB-TS PROFIBUS Troubleshooting Training, 3-Day

Analyse SW

Universal Software for All Diagnostic Tools of the bus check Family
PC software for performing, evaluating and managing tests of bus physics, bus communication and cabling in PROFIBUS networks. The application is extremely easy to use, with a quick test available at a click of the mouse.

One Software for All Diagnostic Products

  • Comprehensive analysis of PROFIBUS DP and PROFIBUS PA networks
  • Diagnostic functionality available depending on connected test tool
  • License-free use on any number of PCs – no activation required

Suitable for the Fieldbus Novice

  • Bus test initiated with a single mouse click
  • Clear, easy-to-read display of test results
  • Separate expert mode providing in-depth diagnostic features for network specialists

Functionality for All Diagnostic Tasks

  • Continuous display of current bus status in status bar
  • Overall bus health indicated by traffic light symbols for bus physics and bus communication
  • Detail views with additional diagnostic information, also for advanced analyses by experts
  • Testing of bus and connected devices via integrated master simulator without configuration or parameterization
  • Generation of test reports for acceptance testing of PROFIBUS installations

Functionality of the Test Tools

Technical Data

Operating Systems:
PC Hardware*		 RAM 500 MB for Windows XP
1 GB for Windows 7, Windows 8
Processor 1 GHz for recording at baud rates up to 1.5 Mbit/s
2 GHz for recording at baud rates over 1.5 Mbit/s
Screen Resolution 1024 x 768 pixels (XGA)
USB Interface 2.0
Supported Operating Systems Windows XP, Windows 7, Windows 8

* The above minimum requirements are only general guidelines. Requirements may vary depending on the PC/notebook used.

Order Number

PB-DIAG-SUITE PROFIBUS Diagnostics Suite

Scope of Delivery

Software PROFIBUS Diagnostics Suite, PC software on CD-ROM for PROFIBUS Tester 5 BC-700-PB, PROFIBUS Tester 4 BC-600-PB and PROFIBUS Monitor BC-502-PB
Documentation Manual “Getting Started”

Additional Products and Services

TRA-PB-TECH PROFIBUS Technology Training, 2 Days
TRA-PB-TS PROFIBUS Troubleshooting Training, 3 Days

Accessoires

Fieldbus Shield Digital Leakage Current Clamp – Locating EMC Problems
Measures leakage currents, e.g. leakage and fault currents, and current pick-up of instruments without breaking the circuit. Measurements according to DIN VDE 0701/0702 and the German BetrSichV (BGV A3, VBG 4).
  • Reliably Detects Even Very Small Improper Shield Currents Resulting from EMC Problems.
 Fieldbus Shield Digital Leakage Current Clamp

Functionality

Included in Package
  • Leakage current measurement
  • Differential current measurement
  • Voltage and resistance measurement
  • Frequency range for AC current / voltage 40 Hz…1 kHz
  • Acoustical continuity test
  • MIN/MAX and relative value measurement
  • Manual selection of the measurement range
  • Integrated data hold
  • Additional analog bar graph display
  • Clamp opening 30 mm
  • Auto power off
 Digital leakage current clamp, 2 batteries 1.5 V IEC LR6, carrying case, measuring cables (1 x red, 1 x black) and user manual.

Order Number:

PB-LSZ-CHB3

Interface for Providing an Access Point to Test PROFIBUS Networks if the D-sub Connectors have no Service Socket or if the Devices are Connected via Terminal Block
Provides an access point for testing PROFIBUS networks if the D-sub connectors have no service socket or if the stations are connected via terminal block.
  • Allows Testing the Bus During Operation
  • Exchange of Bus Devices at the Beginning or End of the Bus Without Causing Problems on the Bus
 D-Sub Service Interface

Application

The service interface is top hat rail mounted. An external 24 VDC power source is required for power supply to the terminating resistor in the PROFIBUS connector included in the package. The service interface can thus be used as an active bus termination at the beginning or end of the bus. If the PLC allows dropping and adding bus stations on the live bus, the service interface offers the possibility to exchange the first and last bus stations without causing problems on the bus. Application example:Application Example D-Sub Service Interface

Included in Package

PBMB adapter and 90° angled PROFIBUS connector with switchable terminating resistor, strain relief and screw terminal technology.

Order Number:

BC-PBMB-PB-S

Interface for Providing an Access Point to Test PROFIBUS Networks With M12 Connectors
Provides an access point for testing PROFIBUS networks with M12 connectors.
  • Allows Testing the Bus During Operation
 M12 Service Interface

Application

The service interface is inserted between two bus stations. When not in use, the service output of the T piece is closed with an end cap. At baud rates of 1.5 Mbit/s or higher, use the supplied cable to ensure that the required minimum distance between bus stations is maintained. Application example:

Application Example M12 Service Interface

Downloads

Included in Package

T piece (protection class IP68) with end cap and a 1 m DP cable fitted with a male/female M12 connector on each end.

Order Number:

BC-M12DP-PB

PB-PRO1-PCIE

Carte universelle PROFIBUS, format PCI Express, pour une utilisation Maitre ou Esclave

Simple ou double canaux, l’interface PB-PRO1 est une interface au format PCI Express pour l’intégration de PC/ Servers dans une architecture PROFIBUS. la carte PB-PRO1-PCIE, permet d’utiliser vos PC comme “contrôleur”, Système de contrôle d’applications et panneau opérateur.

Apperçu

Support of PROFIBUS Master or Slave Functionality

The protocol required for the specific use case is user selectable and executed on the PBpro PCI Express board. As a DP slave, the board integrates the PC into overlying control architectures. Configured as a DP master, the board turns the PC itself into the controller. As a DP Master Class 2, it provides the basis for parameterization and asset management tasks. In addition, integration into FMS systems or proprietary applications is just as easy and unproblematic as direct access at the lowest protocol level (FDL). This makes the PBpro PCI Express a universal interface solution and allows manufacturers to optimize the overhead costs and the inventory for their PROFIBUS options.

Rapid Integration With the Right Software Interface

The included PROFIBUS driver software is complemented with many sample programs that demonstrate how to use the PROFIBUS API. Commented sample programs show how this is done. A matching Softing OPC Server, which is available as an optional standard interface, quickly and easily connects any application that has an integrated OPC client. Typical applications include visualization, SCADA or MES systems. FDT compliant parameterization tools use the PROFIdtm Communication DTM from Softing as a link to the board. Used with the free STEP7 driver, the board can also provide a PG/PC adapter for programming Siemens controllers.

Application in a Wide Variety of Target Systems

In addition to standard Windows environments, the PBpro PCI Express board also supports Windows CE.NET as a real-time environment. On request, Softing’s team of engineers can customize the board according to customer specifications.

Détails techniques

Master/Slave, Single Channel 1)  Slave, Single Channel 1) Master/Slave, Dual Channel
PROFIBUS Protocol
DP-V0 Master
DP-V1 Master: Acyclic C2 Services
FMS
FDL
DP-V0 Slave
Fieldbus Connection 9-Pin D-Sub Female, RS485, Galvanically Isolated
Transfer Rates 9.6; 19.2; 45.45; 93.75; 187.5; 500; 1500; 3000; 6000; 12000 Kbit/s
PC Interface PCI Express x1 According to PCIe r1.0a and CEM 1.1, 512 KB Shared RAM per Channel
Operating Temperature 0 oC .. +55 oC
Storage Temperature -20 oC .. +70 oC
Relative Humidity < 90%, Non-Condensing
Dimensions [mm] 168 x 69  168 x 69 168 x 103
Power Supply
Supply Voltage 3.3V / 12V (± 5%) DC
Current Consumption [mA] typ. 500 / 90 typ. 500 / 90 typ. 640 / 170
Drivers available for Windows 2000, Windows XP, Windows Vista, Windows 7, Windows 8, Windows 10
Conformity

Numéro de référence

PB-PRO 1-PCIE (PB-PRO 1-PCIE/LP1)) Master/Slave, Single Channel 1)
PB-PRO 1S-PCI E(PB-PRO 1S-PCIE/LP1)) Slave, Cingle Channel 1)
PB-PRO 2-PCIE Master/Slave, Dual Channel

Scope of Delivery

PC interface Board, CD with Drivers, Documentation and Sample Programs

Additional Products and Services

OPC-PB PROFIBUS OPC Server for DP-V0 / DP-V1
DCF-DY-4100 OPC Server for S7 / S5
TRA-PB-TECH PROFIBUS Technology Training

1) Also Available with Low Profile Slot Bracket

ATEVA Technologie > Interfaces Profibus >  PB-PRO1-PCIE

THLink – PROFINET

PROFINET : THLink Profinet

Diagnostic PROFINET : Indépendant du contrôleur

L’outil de diagnostic THLink PROFINET est totalement indépendant du contrôleur. Il permet le “monitoring” des réseaux PROFINET.  Les données sont collectés dans des réseaux comprenant jusqu’à 254 Noeuds et mise à la disposition des utilisateurs via le logiciel THScope. THLink PROFINET facile d’utilisations’intègre facilement sans intéraction avec le fonctionnement de l’installation existante.

Général

Independent Access to PROFINET Network

  • Controller-independent
  • Independent of configuration tools
  • Only one tool needed to monitor multiple IP subnetworks (up to 254 nodes, one or more controllers)

Designed for Installation without Interference with Plant Operation

  • Connection to free port in PROFINET network, also possible during operation of the plant
  • No need to install TAPs or use mirror ports
  • Highest security (separate accesses for control room level and plant level, no routing)
  • Easy integration into existing plants thanks to compact design

Powerful Data Collection Capabilities Optimized for PROFINET

  • Collection from PROFINET devices and other nodes (e.g. PCs or camera systems)
  • PROFINET supervisor in PROFINET networks
  • Network load limit according to PROFINET guidelines

Optimized for Use by Maintenance Engineers

  • Suitable for network acceptance testing, continuous monitoring and troubleshooting
  • Easy and intuitive handling and operation
  • Fault identification with intelligent troubleshooting assistance
  • Seamless integration with TH SCOPE diagnostics software

Détails techniques

Functionality
  • Network detection and data collection (active/passive for PROFINET Networks)
  • Alarm notification in case of fault
  • Basic monitoring, configuration
  • Integrated web server
Input Voltage 24 VDC (18 VDC … 32 VDC)
Current consumption max. 180 mA
Current consumption relay contact max. 100 mA
Operating Temperature -40 °C … +75 °C
Relative Air Humidity 5 … 95 % (no condensation)
Ethernet Ports RJ-45 (10Base-T/100Base-TX)
Supported SD Cards See Release Notes
Mounting 35 mm DIN rail
Dimensions (HxWxD) 22.5 x 99 x 114.5 mm
Weight 120 g
Certifications CE

Numéro de référence

GDA-JA-003034 TH LINK PROFINET

Scope of Delivery

Hardware TH LINK PROFINET
Documentation Installation Manual, Release Note (by download)

Additional Products and Services

LRA-JY-003024 TH SCOPE (software key)
LRL-JY-003025 TH SCOPE (hardware key)
LRA-JY-003028 TH LINK PC Industrial Ethernet (software key)
LRL-JY-003029 TH LINK PC Industrial Ethernet (hardware key)
GDA-JY-003037 TH LINK Industrial Ethernet
TRA-PN-TECH Training “PROFINET Technology”
TRA-PN-CERTENG Training “PROFINET Commissioning and Troubleshooting”

Wiki

TH LINK:
enablement of the following ports:

  • HTTP Protocol:      80 TCP
  • Firmware update: 1100 TCP
  • communication with each other:    1123, 1124, 2364 UDP
  • communication with TH SCOPE via Multicast:  2364 UDP
  • communication with TH SCOPE via Unicast:    1151, 2365 UDP

There must be no firewall between the TH LINK and the PROFINET and/or EtherNet/IP devices.

TH SCOPE:
If your network is protected by a second firewall in addition to the Windows firewall, make sure that the following settings are made to allow TH SCOPE services to communicate properly.

  • Enabling of HTTP port 80 – inbound and outbound
  • Enabling of SNMP port 161 inbound or port 2367 (if port 161 is used by another SNMP agent).
  • Enabling of IP 224.0.5.128 port 2364 UDP outbound
  • Enabling of UDP ports 2365 outbound and 2366 inbound



The following ports are used by TH SCOPE for internal communication only:

  • Port 22
  • Port 80
  • Port 1100
  • Ports 1123 – 1151
  • Port 1500
  • Port 1501
  • Ports 2363 – 2366
  • Ports 49152 – 49171

Produits qui pourrait vous intéresser

BC-230-PB

BC-230-PB : Testeur Profibus PA : Pour les Zones ATEX et non-ATEX

BC-230-PB

Le testeur PROFIBUS PA ( BC-230-PB) est un outil pratique et indispensable pour les tests de réseaux PROFIBUS PA ( Zone ATEX et non ATEX )

Test du bus PA, facile et rapide

Le  moniteur de diagnostic est un outil polyvalent et indispensable pour la mesure des réseaux Profibus PA. C’est auss un produit ATEX, ce qui en fait un appareil utilisable en zone a risque. Pas de besoin de batterie ni de source électrique externe.

Général

Application universelle pour ce testeur profibus PA ( BC-230-PB )

  • Test du bus physic
  • Verification de la stabilité entre les différents devices
  • Outil universel pour l’installation, la mise en service, la documentation, la maintenance préventive et le diagnostic

Très simple d’utilisation

  • Outstanding ease of use based on display and two function buttons ▪ Clear classification of test results as either OK or BAD
  • Ideal choice even for less experienced users

Test de bus totalement automatique

  • Automatically powered by fieldbus and start of segment testing without operator intervention after attachment to PROFIBUS PA network
  • Information in plain text, if measured data exceeds tolerance limits
  • Measurement of segment voltage as well as average noise and peak noise for three frequency ranges
  • Reliable detection of short circuits between individual signal wires and cable shield
  • Detection of all frame retransmissions and all devices added or dropped during bus operation at field device level
  • Determination of current and lowest signal levels of all devices
  • No PC or notebook needed for testing the bus
  • Internal storage of test data for later transfer to PC
  • Detailed test reports in Microsoft Excel or text format

Details téchnique

put voltage: Fieldbus mode: 8 to 32 VDC, USB mode: 4.1 to 5.5 VDC
Max. input current: Fieldbus mode: 10 mA *, USB mode: 30 mA
Power dissipation: Fieldbus mode: max. 320 mW (at 32 VDC), USB mode: max. 165 mW (at 5.5 VDC)
Operating temperature: –20 to +50 °C **
Dimensions: 146 x 88 x 28 mm
Weight: 378 g
Case material: ABS
DC voltage measurement range: 8 to 32 VDC ± 0.5 VDC
Signal level measurement range: 0.12 to 2 Vpp ±10% ±0.025 Vpp
LF noise measurement range: 50 Hz to 4 kHz, 0 to 1000 mVpp ±15% ±25 mVpp ***
FF noise measurement range: 9 kHz to 40 kHz, 0 to 1000 mVpp ±10% ±25 mVpp ***
HF noise measurement range: 90 kHz to 350 kHz, 0 to 250 mVpp ±20% ±25 mVpp ***
Conformity CE, FCC
Hazardous area approvals FM USA and Canada:
—Class I Division 2 Groups A, B, C and D T4
—Class I Zone 2 Group IIC T4
—Class I Division 1 Groups A, B, C and D T4
—Class I Zone 0 and 1 Ex/AEx ia IIC T4
ATEX Ex ia IIC T4
ATEX Ex nL IIC T4
ATEX Ex ic IIC T4
Data transfer to PC Via supplied PC software for Windows 2000, XP and VISTA, Windows 7 (32/64 bit) and USB interface version 1.1 or 2.0
*  In  fieldbus  mode  the BC-230-PB  is powered by the  fieldbus and draws approximately 9.4 mA of current from the segment (depending on bus voltage and ambient temperature).
**  Display update speed is impaired below –10°C.
*** Vpp = Volts peak-to-peak; excessive noise adjacent to the fieldbus frequency (FF) band will prevent the BC-230-PB from reading the fieldbus data and thus reduce functionality.

Références

BC-230-PB Diagnostic Monitor for PROFIBUS PA

Scope of Delivery

Hardware Diagnostic Monitor for PROFIBUS PA (BC-230-PB), connection cables, carrying case
Software PC software (in English) on CD-ROM
Documentation Manual (in English), certificates (in English)

Additional Products and Services

PB-LSZ-CHB3 Digital fieldbus leakage current clamp for locating EMC problems, 40 Hz … 1,000 Hz, Min/Max, Data Hold, measuring cables, supplied in handy case

Formation

Pour toute demande, nous consulter

Ce produit fait partie de  la famille des “Process automation”. Afin de connaitre notre gamme complete de produits, vous pouvez télécharger notre brochure :  Process Automation.

PB-PRO1-PCI

PB-PRO1-PCI

Carte d’interface à un ou deux canaux au format PCI universel pour l’intégration des PC dans les architectures PROFIBUS en tant que contrôleurs de machines, applications de contrôle de supervision, dispositifs de terrain ou panneaux opérateurs.

csm_PBproPCI_D_EN_160801_201_a68cf76cc9

Aperçu

Fonctionalité PROFIBUS Maître et esclave supportée

Le protocole requis pour le cas d’utilisation spécifique peut être sélectionnable par l’utilisateur et exécuté sur la carte PBpro PCI. En tant qu’esclave DP, la carte intègre le PC dans des architectures de contrôle superposées. Configurée comme maître DP, la carte transforme le PC lui-même en contrôleur. En tant que DP Master Class 2, il constitue la base des tâches de paramétrage et de gestion d’actifs. En outre, l’intégration dans des systèmes FMS ou des applications propriétaires est tout aussi simple et sans problème que l’accès direct au niveau de protocole le plus bas (FDL). Cela fait du PBpro PCI une solution d’interface universelle et permet aux fabricants d’optimiser leurs productions et l’inventaire pour leurs options PROFIBUS.

Intégration rapide grâce à l’interface adaptée

Le logiciel de pilote PROFIBUS inclus est complété par de nombreux exemples de programmes qui démontrent comment utiliser l’API PROFIBUS. Des exemples de programmes commentés montrent comment faire. Un serveur OPC Softing correspondant, qui est disponible en tant qu’interface standard facultative, se connecte rapidement et facilement à n’importe quelle application qui possède un client OPC intégré. Les applications typiques incluent la visualisation, les systèmes SCADA ou MES. Les outils de paramétrage compatibles FDT utilisent le PROFIdtm Communication DTM de Softing comme lien vers la carte. Utilisée avec le pilote STEP7 (gratuit), la carte peut également fournir un adaptateur PG / PC pour la programmation des automates Siemens.

Grande variété d’applications

la carte prend en charge de nombreux autres systèmes d’exploitation et environnements en temps réel. Sur demande, nous pouvons personnaliser les drivers, selon les spécifications du client.

Données Techniques

Master/Slave, Single Channel 1) Slave, Single Channel 1) Master/Slave, Dual Channel
PROFIBUS Protocol
DP-V0 Master
DP-V1 Master: Acyclic C2 Services
DP-V2 Master 2)
FMS
FDL
DP-V0 Slave
Fieldbus Connection 9-Pin D-Sub Female, RS485, Galvanically Isolated
Transfer Rates 9.6; 19.2; 45.45; 93.75; 187.5; 500; 1500; 3000; 6000; 12000 Kbit/s
PC Interface PCI V2.2, 128 KB Shared RAM per Channel
Operating Temperature 0oC..+55oC
Storage Temperature -20oC..+70oC
Relative Humidity < 90%, Non-Condensing
Dimensions [mm] 168×64 168×64 168×107
Power Supply
Supply Voltage 5V/3.3V(±5%)DC
Current Consumption [mA] Typ. 500 / 200 Typ. 500 / 200 Typ. 700 / 300
Drivers available for Windows 2000, Windows XP, Windows Vista, Windows 7, Windows 8, Windows 10
Linux
Conformity

1) Also Available with Low Profile Slot Bracket
2) DP-V2 Available for Custom Integration. Please contact Softing to discuss your specific requirements.

Reference

PB-PRO 1-PCI (PB-PRO 1-PCI/LP1)) Master/Slave, Single Channel 1)
PB-PRO 1S-PCI (PB-PRO 1S-PCI/LP1)) Slave, Single Channel 1)
PB-PRO 2-PCI Master/Slave, Dual Channel

Scope of Delivery

PC interface Board, CD with Drivers, Documentation and Sample Programs

Additional Products and Services

OPC-PB3) PROFIBUS OPC Server for DP-V0 / DP-V1
DCF-DY-41003) OPC Server for S7 / S5
TRA-PB-TECH PROFIBUS Technology Training

1) Also Available with Low Profile Slot Bracket
3) Requires PROFIBUS Master Interface Board

Formation

Formation disponible. Pour plus d’information, contactez nous





ATEVA Technologie > Interfaces Profibus >  PB-PRO1-PCI

Testeur PROFIBUS : PB-T5 (BC-700-PB)

Testeur Profibus: SOFTING PB-T5 ( BC-700-PB ) : Pour Test rapide et facile;  bus physique, bus de communication et câblage de vos réseaux PROFIBUS

BC-700-PB
profibustester5bc-700-pb_d_en_160401_200

Le testeur PROFIBUS: ‘PROFIBUS Tester 5’ (BC-700-PB) est un outil de diagnostic et de dépannage puissant pour tester les câbles, mesurer les signaux et l’analyse de la communication de réseaux PROFIBUS. Il est alimenté par batterie et fournit un affichage graphique, ce qui permet des résultats rapides lorsque vous travaillez en mode autonome. En option, également le réseau PROFIBUS PA peut être analysé. En outre, le BC-700-PB soutient l’exportation des résultats des tests pour l’analyse avancée.

Général

Le testeur profibus vous permet le test des câbles, bus physique et bus de communication “All-In-One”

  • Combinaison de testeur de signal, oscilloscope à mémoire, protocolanalyzer, simulateur de maître et la fonctionnalité de testeur de câble en un seul outil de diagnostic
  • Mode autonome, plus des diagnostics basés sur PC étendues
  • Adaptés pour l’installation, la configuration et la mise en service, la documentation, les tests d’acceptation, l’optimisation du réseau, la maintenance préventive, le dépannage ainsi que des tests de laboratoire

Très mobile, le testeur de bus permet des tests, même sans ordinateur

  • fonctionnement sur batterie sans avoir besoin d’alimentation supplémentaire
  • Affichage graphique fournissant facile à comprendre la présentation des résultats des tests
  • tests de réseau complets en mode autonome sans nécessiter un ordinateur portable

Caractéristiques de diagnostic améliorée grâce à complément logiciel PC-Based

  • De nombreuses fonctionnalités supplémentaires pour l’exécution, l’analyse et la gestion des tests de bus en mode PC (Tendance, Topologie Numériser, Master Simulator, Oscilloscope, analyseur Frame)
  • Test rapide et test contrôlé par l’utilisateur pour l’évaluation de l’état du réseau facile à la simple pression d’un bouton
  • Génération de rapports d’essais qui décrivent l’état actuel de l’installation PROFIBUS
  • Idéal pour les utilisateurs moins expérimentés, ainsi que pour les spécialistes de bus de terrain

Adaptateur de mesure en option pour MBP (Manchester Coded Bus Powered) Physique

  • Analyse spécifique du signal de support physique MBP (de feedingvoltage, type de signal, le signal de polarité, divergence bitrate)
  • Analyse complète du protocole directement au niveau du segment PROFIBUS PA

Détails techniques

Diagnostics Functionality
Protocol and Frame Analysis PROFIBUS DP-V0 and DP-V1, automatic baud rate detection in the range of 9.6 kbit/s … 12 Mbit/s
Signal Analysis PROFIBUS DP-V0, DP-V1, FMS and MPI
… via EIA-485 Signal quality index 0 … 5,000, determined from signal wave form as well as signal/noise ratio and rise time; signal sampling with 8/16 samples per bit
… via MBP
(requires optional adapter)		 Fieldbus feeding voltage: 0 V … 35 V at 0.1 V resolution, signal level: 100 mV … 1,200 mV at 10 mV resolution, signal polarity, bitrate divergence: ±1.2 % at 0.01 % resolution, signal sampling with 128 samples per bit
Oscilloscope Display
(Not Available for MBP)		 Test range: ±5 V at 10 mV resolution (differential), 0 V … 15 V at 15 mV resolution (A or B to DGND);
sampling rate: up to 384 Msamples/s; sampled points: 2,400 (signal details), 8,192 (oscilloscope analysis)
Topology Scan
(Not Available for MBP)		 Active, maximum distance: 230 m, accuracy: ±2 m
Cable Test
(Not Available for MBP)		 Active, supported cable segment length: 5 m … 1,500 m, accuracy: 5 %
Operation Via graphical colour display, four function keys and scrollwheel including central push-button or via PC/notebook
Internal Memory Capacity 3 user-definable network directories (segment and test location) for storing quick tests, trend logs and cable test results
Trend logging: max. 99 hours
Trigger IN: L = 0 V .. 0.8 V; H = 2.4 V .. 24 V; pulse > 10 μs, active high
OUT: approximately 5 V, active low (connection to storage oscilloscope)
PC Operating Software PROFIBUS Diagnostics Suite, see separate datasheet for details
Connectors
EIA-485 (PROFIBUS DP) PROFIBUS D-sub connector, 9 pins, power supply for external bus termination
MBP (PROFIBUS PA) Connector, 3 pins, for screw terminals at optinal measuring adapter, measuring cable set including 3 probes(adapter for MBP measurement is attached to D-sub connector)
USB V 2.0, high speed 480 Mbit/s, galvanically isolated
Dimensions (H x W x D) 35 mm x 220 mm x 110 mm
Power Supply Built-in three-cell lithium-ion battery supporting 11.1 VDC or external AC adapter 100 VAC … 240 VAC, 50/60Hz (galvanically isolated)
The rechargeable battery has a runtime of up to 5 hours (runtime depends on the performed test functionality and rate of wear of the rechargeable battery)
Battery is charged via external AC adapter
Operating/Storage Temperature Operating temperature: 0 °C … 50 °C, storage temperature: -20 °C … 70 °C
Relative Humidity Air humidity: 10 % … 90 % without condensation
Weight Test tool, no cable: approximately 0.75 kg; complete carrying case: approximately 4.2 kg
Conformity CE, FCC, VCCI

Numéro de référence

ATV-DDA-NN-006014 PROFIBUS Tester 5 (BC-700-PB)
ATV-DDL-NN-006012 PROFIBUS Tester 5 (BC-700-PB) with Oscilloscope Option
ATV-LRA-NN-006011 Oscilloscope Option (Oscilloscope view in stand-alone mode)
ATV-DDL-NL-006010 PROFIBUS PA option for BC-700-PB (BC-700-PB serial number required for order placement)

Scope of Delivery

Hardware PROFIBUS Tester 5 (BC-700-PB), power supply unit 100 VAC … 240 VAC, 50/60 Hz with connecting cables for Europe and USA, adaptor cables, carrying case
Measuring adapter BC-700-H1, measuring cable set (for PROFIBUS PA option)
Software PROFIBUS Diagnostics Suite (PC software for Windows on CD-ROM)
BC-700-PB upgrade license (on CD-ROM, for PROFIBUS PA option)
Documentation Device Manual, “Getting Started“ Manual

Additional Products and Services

ATV-ACA-NN-006031 EIA-485 D-Sub adapter cable for testing operational networks with reduced influence on segment operation
ATV-ACA-NN-006033
(view product)		 Adapteur D-Sub vers M12, fourni avec un T et bus M12 de terminaison, pour profibus DP
ATV-PB-LSZ-CHB3
(view product)		 Pince pour mesure des courants de fuite. Localise les problèmes électromagnétique ( EMC ) . 40 ..1000 Hz, MIN/MAX, Data Hold, Cable pour mesure, fourni avec son étui.
ATV-BC-PBMB-PB-S
(view product)
 D-Sub Service Interface with Active Bus Termination and 90° Angled Connector for PROFIBUS DP
ATV-BC-M12DP-PB
(view product)
 M12 Service Interface for PROFIBUS DP, Comprising M12 T-Piece, End Cap and M12 Connection Cable (1 m)

Analyse SW

PROFIBUS Diagnostics Suite

Universal Software for All Diagnostic Tools of the bus check Family
PC software for performing, evaluating and managing tests of bus physics, bus communication and cabling in PROFIBUS networks. The application is extremely easy to use, with a quick test available at a click of the mouse.

One Software for All Diagnostic Products

  • Comprehensive analysis of PROFIBUS DP and PROFIBUS PA networks
  • Diagnostic functionality available depending on connected test tool
  • License-free use on any number of PCs – no activation required

Suitable for the Fieldbus Novice

  • Bus test initiated with a single mouse click
  • Clear, easy-to-read display of test results
  • Separate expert mode providing in-depth diagnostic features for network specialists

Functionality for All Diagnostic Tasks

  • Continuous display of current bus status in status bar
  • Overall bus health indicated by traffic light symbols for bus physics and bus communication
  • Detail views with additional diagnostic information, also for advanced analyses by experts
  • Testing of bus and connected devices via integrated master simulator without configuration or parameterization
  • Generation of test reports for acceptance testing of PROFIBUS installations

DIvers

Technical Data

Operating Systems:
PC Hardware*		 RAM 500 MB for Windows XP
1 GB for Windows 7, Windows 8
Processor 1 GHz for recording at baud rates up to 1.5 Mbit/s
2 GHz for recording at baud rates over 1.5 Mbit/s
Screen Resolution 1024 x 768 pixels (XGA)
USB Interface 2.0
Supported Operating Systems Windows XP, Windows 7, Windows 8, Windows 10

* The above minimum requirements are only general guidelines. Requirements may vary depending on the PC/notebook used.

Accessoires

Fieldbus Shield Digital Leakage Current Clamp – Locating EMC Problems

Fieldbus Shield Digital Leakage Current Clamp - Locating EMC Problems

Measures leakage currents, e.g. leakage and fault currents, and current pick-up of instruments without breaking the circuit. Measurements according to DIN VDE 0701/0702 and the German BetrSichV (BGV A3, VBG 4).

  • Reliably Detects Even Very Small Improper Shield Currents Resulting from EMC Problems.

Functionality

  • Leakage current measurement
  • Differential current measurement
  • Voltage and resistance measurement
  • Frequency range for AC current / voltage 40 Hz…1 kHz
  • Acoustical continuity test
  • MIN/MAX and relative value measurement
  • Manual selection of the measurement range
  • Integrated data hold
  • Additional analog bar graph display
  • Clamp opening 30 mm
  • Auto power off

Included in Package

Digital leakage current clamp, 2 batteries 1.5 V IEC LR6, carrying case, measuring cables (1 x red, 1 x black) and user manual.

Order Number

DDA-ZZ-004010

M12 Service Interface for PROFIBUS DP

M12 Service Interface for PROFIBUS DP

Application example:

Example Application M12 Service Interface for PROFIBUS DP

Interface for Providing an Access Point to Test PROFIBUS Networks With M12 Connectors

Provides an access point for testing PROFIBUS networks with M12 connectors.

  • Allows Testing the Bus During Operation

Application

The service interface is inserted between two bus stations. When not in use, the service output of the T piece is closed with an end cap. At baud rates of 1.5 Mbit/s or higher, use the supplied cable to ensure that the required minimum distance between bus stations is maintained.

Included in Package

T piece (protection class IP68) with end cap and a 1 m DP cable fitted with a male/female M12 connector on each end.

Order Number

ATV-ACA-NN-006034



ATV-ACA-NN-006034

M12 adaptor PROFIBUS Tester  PB-T5

Application example:

Interface for Providing an Access Point to Test PROFIBUS Networks With M12 Connectors

M12 Adaptor for PB-T5

  • Allows Testing the Bus During Operation

Application

The service interface is inserted between two bus stations. When not in use, the service output of the T piece is closed with an end cap. At baud rates of 1.5 Mbit/s or higher, use the supplied cable to ensure that the required minimum distance between bus stations is maintained.

Included in Package

M12 Adaptor for PB-T5

Order Number

ATV-ACA-NN-006033



Les clients intéressé par ce produit peuvent  aussi etre intéressé par :
