Logiciel de configuration de réseaux Profibus DP

PROFIBUS DP Configurator

Configurateur de réseaux PROFIBUS DP : V 2.02.98

Outil de configuration de cartes Softing pour réseaux PROFIBUS DP. Il permet à l’utilisateur de configurer le réseau et de définirla carte comme maître. Le configurateur peut être utilisé dans de nombreuses applications pour configurer les cartes Softing comme Maître.
En fonction du cas d’utilisation, la fonctionnalité va de la définition de la structure du réseau avec ses appareils connectés et leurs paramètres, en passant par des tests interactifs en ligne d’entrées et de sorties spécifiques jusqu’à la définition de noms de points et de types de données pour toutes les données de processus disponibles au fur et à mesure de leur utilisation, comme pour être utilisé par un serveur OPC

Offline configuration
L’objectif d’une configuration hors ligne est de préparer un fichier de configuration binaire pour un contrôleur utilisant un maître Softing PROFIBUS DP. Le maître PROFIBUS DP peut être basé sur une carte d’interface PC ou implémenté en tant que solution intégrée utilisant les piles de protocoles et les cœurs IP de Softing.

Online configuration
La configuration en ligne utilise des cartes d’interface PROFIBUS installées sur le PC, sur lequel le configurateur PROFIBUS est utilisé.

Cela permet de rechercher sur le réseau, les périphériques connectés et de communiquer interactivement avec ces périphériques. Une configuration réseau peut être activée en utilisant la carte d’interface en tant que maître actif pour les périphériques connectés. Définition des noms de variable pour les variables

Pour chaque appareil configuré, il est possible d’affecter des variables de processus nommées à ses entrées et à sa sortie. Un type de données est également affecté à ces variables (par exemple, une valeur booléenne pour un seul bit ou un octet signé pour une entrée analogique). Ces variables peuvent ensuite être utilisées dans le configurateur PROFIBUS à des fins telles que la mise en service du réseau. Pour cela, les variables peuvent être lues et écrites dès l’activation de la configuration actuelle.
De plus, les variables nommées servent d’ « OPC Items », si la configuration est utilisée pour un serveur OPC PROFIBUS de chez Softing.

Documents

Logiciel

Version disponible avec une carte SOFTING , comme clef hardware

Version gratuite disponible avec l’achat d’un carte Softing



=======================  Version End Of Life ===============

Référence : VCL-NN-017210

Sera délivré : Un logiciel et une clef USB

PB-IF-03

PB-IF-03 : Carte Profibus, 1 canal, format ISA

S5 PCLink

PROFIboard une carte PC intéligente dans un réseau PROFIBUS DP. Elle est facile d’utilisation

Des applications tel que HMI, SCADA, interface ou controleur PC, peuvent accéder facilement aux réseaus PROFIBUS DP, grâce à cette carte.

. PB-IF-03

  • Carte Profibus  : 1 canal format : ISA

  • Specific ; ISA spec

  • Température d’utilisation : [ 0°C / +55°C]

  • Carte rapide à mettre en Oeuvre

  • Support de protocoles variés

Unit PB-IF-03

ISA PC-board, short AT format.

CPU Siemens SAB-C165 Microprocessor
Memory 512-Kbyte Flash, 512 Kbyte SRAM, 16 Kbyte dual port RAM
SUpported PC Interrupts 5,10,11,12,15
Profibus ASIC Siemens ASPC2 and SPC3
Physical Interface Galvanically isolated RS-485

Connector Type

1 x 9 pin Sub-d female
Connector Pinning EN 50 170, part 2 compliant
Hardware Configuration I/O address is set by switch on board; all other settings are software configurable
Power Supply +5 V (+-5%; typ. 700mA
Transfer Rate 9.6KKbit/ up to 12 Mbit/s
Humidity Rating <90% non-condensing
Temperature 0-55C Operating temperature

Reference :  PB-IF-03

Cette carte n’est plus en production. Veuillez vérifier sa disponibilité

Echolink S7 Compact

 echolink S7-compact

Adapteur Profibus/MPI compact pour se connecter aux contrôleurs S7 via Ethernet

  • Integration de S7-200, S7-300 et S7-400 dans des architectures Ethernet
  • Programmation de PLC et communication via Interface
  • Integration à l’aide de  « Product Management » et  applications de visualisation

Integration des S7-200, S7-300 et S7-400 grâce à un réseaux  10/100 Mbit Ethernet

  • Communication directe avec un ou plusieurs contrôleurs sur n’importe quelle structure TCP
  • Supporte jusqu’à 16 connexions simultanées
  • Utilisation standard TCP/IP pour la communication à l’intérieur de l’usine ou du réseau de la société et avec Internet
  • Communication étendue utilisant les ports MPI ou PROFIBUS via le port PG.
  • integration sans interférence dans un système de contrôle existant
  • Configuration centralisée de tous les adapteurs sur le réseau via le logiciel NetCon S7
  • Power supply directly from controller or via external power supply
  • Cost-effective solution alternative

Programming Adapter Supporting all Relevant S7 Engineering Tools

  • Interface for programming controllers via Ethernet
  • Compatibility with STEP7, TIA-Portal, WinCC and WinCC flexible
  • Display and configuration of the adapter in STEP7 or TIA portal

Application Integration through RFC1006 and OPC UA

  • Connection to HMI station and PLC directly via RFC1006 Ethernet protocol
  • Support of OPC and OPC UA by using dataFEED OPC Suite for integration into higher-level systems, e.g. for production management
Hardware Requirements Ethernet Interface
PC Connection RJ45
Supported Controllers Siemens S7-200, Siemens S7-300, Siemens S7-400
Supported Bus Systems PROFIBUS, MPI
Communication Type Ethernet 100 BASE-TX/10 BASE-T
Supported Transfer Rates to PLC 9.6 KBit/s … 12 MBit/s with automatic detection
Supported Transfer Rates to PC 10 / 100 MBit/s
Simultaneous Connections 16 TCP/IP, 32 MPI / PROFIBUS Connections
Power Supply 24V ± 25%, external or from Controller
Galvanic Isolation Yes
Temperature Range 0°C … +55°C
Housing, Dimensions (W x H x D) 40,6 mm x 16,7 mm x 74,3 mm
Weight Approximately 40g
Approvals CE
Protection Class IP20
Configuration Software NetCon S7 for Local and Remote Configuration
Supported Application Software Siemens TIA Portal V11-V13, Siemens STEP 7 V5.5, Siemens WinCC, Siemens WinCC flexible, Siemens ProTool
System Requirements PC/PG with Windows XP, Windows 7, Windows 8, Windows 10, Windows Server 2003, Windows Server 2008, Windows Server 2008 R2, Windows Server 2012
ATV-GPL-CS-191000 echolink S7-compact

Scope of Delivery

Hardware echolink S7-compact
Software Configuration Software NetCon S7 on CD-ROM (also downloadable from Softing website)
Documentation Product handbook and configuration tutorials on CD-ROM (also downloadable from Softing website)

Additional Products and Services

ATV-LRL-DY-134501 dataFEED OPC Suite
ATV-LRL-DY-132101 dataFEED OPC Server Siemens
ATV-GAA-DX-145111 uaGate SI
ATV-GAL-YY-143101 echocollect e (and other echocollect variants)
110-1000-01 Training “Industrial Ethernet – Troubleshooting in Automation“, 3 days

TH Link PROFIBUS

TH Link PROFIBUS

TH Link PROFIBUS

Administration et gestion de réseaux avec analyse de réseaux Profibus

Accéder aux réseaux PROFIBUS avec une application FDT, AMS d’Emerson et TH Scope de Softing

THLINK PROFIBUS  fournit un accès indépendant du controlleur, aux réseaux PROFIBUS, pour la gestion et la maintenance.  L’outil supporte à la fois : la gestion du réseaux mais aussi l’analyse du réseaux Profibus.. THLINK PROFIBUS est facile d’utilisation et s’intègre très facilement avec le réseau PROFIBUS existant.

Independent Access to PROFIBUS Network

  • Controller-independent
  • Independent of configuration tools
  • Access for plant asset management applications to configure field devices based on FDT/DTM and EDDL standards (acyclic master)

Designed for Installation without Interference with Plant Operation

  • Connection to PROFIBUS network also possible during operation of the plant
  • Easy integration into existing plants thanks to compact design
  • Browser access for administration and configuration purposes

Powerful Data Collection Capabilities Optimized for PROFIBUS

  • Passive listening to PROFIBUS DP protocol
  • Threshold monitoring for frame retries
  • Statistics for optimization of the network configuration
  • Easy detection of missing terminating resistors

Optimized for Use by Maintenance Engineers

  • Central and time-saving parameterization of PROFIBUS and HART field devices directly from the control room
  • Continuous monitoring and troubleshooting for PROFIBUS networks
  • Fault identification with intelligent troubleshooting assistance
  • Seamless integration with TH SCOPE diagnostics software
Functionality
  • Network detection and data collection (PROFIBUS DP)
  • Acyclic master (PROFIBUS DP-V1)
  • Alarm notification in case of fault
  • Basic monitoring, configuration
  • Integrated web server
Supported Plant Asset Management Applications e.g.:

  • Endress+Hauser FieldCare
  • Emerson AMS Suite
  • Yokogawa Fieldmate
  • PACTware
PROFIBUS Transmission Rate
  • max. 12 MBit/s (AMS Device Manager, FDT)
  • max. 1.5 MBit/s (TH SCOPE)
Input Voltage 24 VDC (19.2 VDC … 28.8 VDC)
Current consumption max. 190 mA
Operating Temperature 0 °C … 50 °C
PROFIBUS interface RS 485
Ethernet Port RJ-45 (10Base-T/100Base-TX)
Mounting 35 mm DIN rail
Dimensions (H x W x D) 22.5 x 99 x 114.5 mm
Weight 120 g
Certificate CE
  • GEA-JN-003006 TH LINK PROFIBUS

    Scope of Delivery

    Hardware TH LINK PROFIBUS
    Documentation Installation Manual, Release Notes (by download)

    Additional Products and Services

    LRA-JY-003024 TH SCOPE (software key)
    LRL-JY-003025 TH SCOPE (hardware key)
    LRA-NN-021980 DTM Library
    VAA-YY-023000 PACTware
    VAA-NM-023001 TACC

DTM Librairies

Libraries DTM  pour Siemens DP/PA Links ET 200M, ET 200SP et PROFIBUS DP v1

Fichiers DTM pour applications « Asset Management » ( FDT/DTM)

Les librairies DTM fournissent un accès principal à PROFIBUS DP, PROFIBUS PA et réseaux HART, pour toutes applications  » Asset Management ». Les librairies DTM inclues le « Communication Devices Type Managers » ( CommDTM) pour les produits Siemens DP/PA link, ET200M et ET200iSP. Combinées avec le THLink PROFIBUS, la solution peut être utilisée pour surveiller un réseau PROFIBUS DP

Librairies FDT/DTM

Increased Efficiency Through Use of Plant Asset Management Applications

  • Fast plant commissioning, fast replacement of defective devices
  • Simple remote device parameterization
  • Central management of all device parameters
  • Comprehensive monitoring of process-critical devices
  • Automatic creation of plant documentation

Standardized FDT/DTM-Compliant Architecture

  • Communication with field devices via PROFIBUS DP, PROFIBUS PA and HART
  • CommDTMs for access to Siemens components DP/PA Link, ET 200M, ET 200iSP
  • Flexible integration into most common plant asset management applications (such as Endress+Hauser  FieldCare, Emerson AMS Suite, Yokogawa Fieldmate, PACTware)

Additional Benefit From Integrated PROFIBUS Monitoring

  • Use of TH LINK PROFIBUS for simultaneous PROFIBUS diagnostics
  • Threshold monitoring for frame retries
  • Statistics for optimization of the network configuration
  • Easy detection of missing terminating resistors

Flexible, Expandable Complete Solution

  • Getting started with plant asset management, e.g. using PACTware, with possibility of later adding further asset management applications
  • TH LINK PROFIBUS optionally expandable by TH SCOPE diagnostics software
Supported Hardware CommDTM PROFIBUS DP-V1
CommDTM DP/PA Link
CommDTM ET 200M
CommDTM ET 200iSP
TH LINK PROFIBUS
SIMATIC DP/PA Link
SIMATIC ET 200M
SIMATIC ET 200iSP
Functionality
  • Access to PROFIBUS PA and HART devicesAdditionally for CommDTM PROFIBUS DP-V1:
  • Integrated bus parameter test ensuring reliable non-reactive parameterization
  • Automatic scan of the PROFIBUS network
  • Frame logging for analysis of acyclic communication between control and field devices
Recommended PROFIBUS Access TH LINK PROFIBUS
Supported Plant Asset Management Applications Field Device Tool (FDT) frame applications compliant with FDT Specification 1.2 with Addendum, e.g. Endress+Hauser FieldCare, Emerson AMS Suite, Yokogawa Fieldmate, PACTware
Supported Operating Systems Windows 7 (English and German, 32 Bit and 64 Bit), Windows 8.1 (English and German, 32 Bit and 64 Bit), Windows Server 2012 R2
System Requirements Adobe Reader 8.0 or higher for reading the documentation
Licensing Complete DTM Library or single CommDTMs
If TH LINK PROFIBUS is used, the CommDTM PROFIBUS DP-V1 is free of charge.
Automatic licensing by Endress+Hauser frame application
Activation of the complete DTM Library provides parallel PROFIBUS access via multiple gateways or interface cards; activation of the PROFIBUS DP-V1 CommDTM supports PROFIBUS access via a single gateway or interface card.
Certifications All CommDTMs of the DTM Library have been certified by an accredited test and certification laboratory of the FDT Group.

Downloads

  • Brochure

  • Drivers et logiciels

    • PACTware
      Framework of PACTware Consortium e. V. for use of FDT 1.2, FDT 1.2.1 or FDT 2 compatible DTMs of individual manufacturers.
ATV-LRA-NN-021980 DTM Library ( package including CommDTMs)

Scope of Delivery

Software DTM Library (by download)
Comprising CommDTM PROFIBUS DP-V1, CommDTM Siemens DP/PA Link, CommDTM Siemens ET200M, CommDTM Siemens ET 200iSP
CommDTMs can be used individually
Documentation Installation Guide, User Manuals for all CommDTMs, Release Note (by download)

Additional Products and Services

ATV-GEA-JN-003006 TH LINK PROFIBUS
ATV-VAA-YY-023000 PACTware

Customers having looked for this product may be interested in the following one.

PB-PRO1-PCIE

Carte universelle PROFIBUS, format PCI Express, pour une utilisation Maitre ou Esclave

Simple ou double canaux, l’interface PB-PRO1 est une interface au format PCI Express pour l’intégration de PC/ Servers dans une architecture PROFIBUS. la carte PB-PRO1-PCIE, permet d’utiliser vos PC comme « contrôleur », Système de contrôle d’applications et panneau opérateur.

Support of PROFIBUS Master or Slave Functionality

The protocol required for the specific use case is user selectable and executed on the PBpro PCI Express board. As a DP slave, the board integrates the PC into overlying control architectures. Configured as a DP master, the board turns the PC itself into the controller. As a DP Master Class 2, it provides the basis for parameterization and asset management tasks. In addition, integration into FMS systems or proprietary applications is just as easy and unproblematic as direct access at the lowest protocol level (FDL). This makes the PBpro PCI Express a universal interface solution and allows manufacturers to optimize the overhead costs and the inventory for their PROFIBUS options.

Rapid Integration With the Right Software Interface

The included PROFIBUS driver software is complemented with many sample programs that demonstrate how to use the PROFIBUS API. Commented sample programs show how this is done. A matching Softing OPC Server, which is available as an optional standard interface, quickly and easily connects any application that has an integrated OPC client. Typical applications include visualization, SCADA or MES systems. FDT compliant parameterization tools use the PROFIdtm Communication DTM from Softing as a link to the board. Used with the free STEP7 driver, the board can also provide a PG/PC adapter for programming Siemens controllers.

Application in a Wide Variety of Target Systems

In addition to standard Windows environments, the PBpro PCI Express board also supports Windows CE.NET as a real-time environment. On request, Softing’s team of engineers can customize the board according to customer specifications.

Master/Slave, Single Channel 1)  Slave, Single Channel 1) Master/Slave, Dual Channel
PROFIBUS Protocol
DP-V0 Master PB-PRO1-PCIE PB-PRO1-PCIE
DP-V1 Master: Acyclic C2 Services PB-PRO1-PCIE PB-PRO1-PCIE
FMS PB-PRO1-PCIE PB-PRO1-PCIE
FDL PB-PRO1-PCIE PB-PRO1-PCIE
DP-V0 Slave PB-PRO1-PCIE PB-PRO1-PCIE PB-PRO1-PCIE
Fieldbus Connection 9-Pin D-Sub Female, RS485, Galvanically Isolated
Transfer Rates 9.6; 19.2; 45.45; 93.75; 187.5; 500; 1500; 3000; 6000; 12000 Kbit/s
PC Interface PCI Express x1 According to PCIe r1.0a and CEM 1.1, 512 KB Shared RAM per Channel
Operating Temperature 0 oC .. +55 oC
Storage Temperature -20 oC .. +70 oC
Relative Humidity < 90%, Non-Condensing
Dimensions [mm] 168 x 69  168 x 69 168 x 103
Power Supply
Supply Voltage 3.3V / 12V (± 5%) DC
Current Consumption [mA] typ. 500 / 90 typ. 500 / 90 typ. 640 / 170
Drivers available for Windows 2000, Windows XP, Windows Vista, Windows 7, Windows 8, Windows 10
Conformity PB-PRO1-PCIE

Downloads

  • Drivers & Software

    • PROFIBUS GSD files
  • Articles & White Papers

  • Certificates

  • Data Sheets

PB-PRO 1-PCIE (PB-PRO 1-PCIE/LP1)) Master/Slave, Single Channel 1)
PB-PRO 1S-PCI E(PB-PRO 1S-PCIE/LP1)) Slave, Cingle Channel 1)
PB-PRO 2-PCIE Master/Slave, Dual Channel

Scope of Delivery

PC interface Board, CD with Drivers, Documentation and Sample Programs

Additional Products and Services

OPC-PB PROFIBUS OPC Server for DP-V0 / DP-V1
DCF-DY-4100 OPC Server for S7 / S5
TRA-PB-TECH PROFIBUS Technology Training

1) Also Available with Low Profile Slot Bracket
