Analyzer IE / PRO

Software for Mobile Diagnostics and Acceptance Testing of Industrial Networks

Analyzer IE / PRO is a comprehensive software solution for acceptance testing and efficient troubleshooting of Ethernet-based industrial communication. In a PROFINET environment, the mobile diagnostic tool generates standardized acceptance reports in accordance with the recommendations of PROFIBUS & PROFINET International (PI), making it an easy-to-use product that is tailored to the needs of plant suppliers, maintenance personnel as well as service providers.

Général

Comprehensive Functionality

Diagnostics list, error statistics, network statistics
Enhanced flexibility by supporting online as well as offline mode
Generation, analysis and handling of diagnostic data such as graphical topology, inventory list and reference measurements, also for standard Ethernet components (eg PCs, camera systems)

Automated Generation of Acceptance Test Documents

Time saving by automatically created test reports
Flexible definition of acceptance criteria
Transparent reporting by following PI guidelines

Tool Addressing Complete Plant Lifecycle

Data on network configuration, network communication and diagnostic messages
Error identification for effective troubleshooting (e.g. based on inventory list of network devices)
Chance to support exchange of general project information between end users, EPC contractors, system integrators and maintenance service providers
Seamless integration with Softing diagnostics per-manent monitoring solutions TH SCOPE and TH LINK

Détails techniques

Technical Data
Functionality	Analysis of device logs Live list, statistics, inventory Topology and trend analysis GSDML file support, plaintext messages in diagnostic list Acceptance measurements and acceptance reports Reference comparison Configurable time intervals for automated export of inventory and topology data Data export via Excel Configurable Blacklist feature for robust operation Optional (Analyzer PRO): Telegram analysis: jitter, refresh interval, load ratio
Supported Protocols	PROFINET, EtherNet/IP, Modbus TCP
Interfaces	SNMP Agent OPC UA Server
System Requirements	Adobe Reader 8 or higher for reading the documentation and for printing the topology
Supported Operating Systems	Windows 7, Windows 8.1, Windows 10 Windows Server 2012, Windows Server 2012 R2, Windows Server 2016
Network Access	Data collection through TH LINK PC (PROFINET, EtherNet/IP, Modbus TCP)
Demo Version	Full TH SCOPE functionality can be used for free for 30 days after installation
Licensing	Software or hardware key

Téléchargements

Drivers & Software
- Network Diagnostics dataCHECK Analyzer V3.5 (Installation for 32-Bit-Systems)
- Network Diagnostics dataCHECK Analyzer V3.5 (Installation for 64-Bit-Systems)
Manuals & Documentation
- Network Diagnostics dataCHECK Analyzer Installation Manual
Data Sheets
- Network Diagnostics dataCHECK Analyzer IE / PRO Datasheet

Numéro de référence

Scope of Delivery
Software	Analyzer IE
License	Software key (bound to PC) or hardware key
Hardware	profiTap: Network tap for telegram analysis operation, optional (Analyzer PRO)
Documentation	Installation manual, user manual, release note

Order Numbers
LRA-JY-003041	Analyzer IE (software key)
LRL-JY-003042	Analyzer IE (hardware key)
KPL-JY-003043	Analyzer PRO

Additional Products and Services
GEA-JN-003006	TH LINK PROFIBUS
GDA-JA-003034	TH LINK PROFINET
GDA-JY-003037	TH LINK Industrial Ethernet
LRA-JY-003028	TH LINK PC Industrial Ethernet
TRA-PB-TECH	Training “PROFIBUS Technology”
TRA-PB-TS	Training “PROFIBUS Troubleshooting with exam to Certified PROFIBUS Installer”
TRA-PN-CERTINST	Training “PROFINET Acceptance and Commissioning”
TRA-PN-CERTENG	Training “PROFINET Technology graduated as Certified PROFINET Engineer”
TRA-PN-TOOLS	On-site training: PROFINET tools
